유니티 VR Full Body IK Setup with Hand Animation

저의 천사 발렘 유튜버님의 영상을 후루룩 해왔습니다!!!

필요한 재료

첫 번째로 Animation Rigging이 필요합니다!

IK Foot Solver

using UnityEngine;

public class IKFootSolver : MonoBehaviour
{
    public bool isMovingForward;

    [SerializeField] LayerMask terrainLayer = default;
    [SerializeField] Transform body = default;
    [SerializeField] IKFootSolver otherFoot = default;
    [SerializeField] float speed = 4;
    [SerializeField] float stepDistance = .2f;
    [SerializeField] float stepLength = .2f;
    [SerializeField] float sideStepLength = .1f;

    [SerializeField] float stepHeight = .3f;
    [SerializeField] Vector3 footOffset = default;

    public Vector3 footRotOffset;
    public float footYPosOffset = 0.1f;

    public float rayStartYOffset = 0;
    public float rayLength = 1.5f;

    float footSpacing;
    Vector3 oldPosition, currentPosition, newPosition;
    Vector3 oldNormal, currentNormal, newNormal;
    float lerp;

    private void Start()
    {
        footSpacing = transform.localPosition.x;
        currentPosition = newPosition = oldPosition = transform.position;
        currentNormal = newNormal = oldNormal = transform.up;
        lerp = 1;
    }

    void Update()
    {
        transform.position = currentPosition + Vector3.up * footYPosOffset;
        transform.localRotation = Quaternion.Euler(footRotOffset);

        Ray ray = new Ray(body.position + (body.right * footSpacing) + Vector3.up * rayStartYOffset, Vector3.down);

        Debug.DrawRay(body.position + (body.right * footSpacing) + Vector3.up * rayStartYOffset, Vector3.down);

        if (Physics.Raycast(ray, out RaycastHit info, rayLength, terrainLayer.value))
        {
            if (Vector3.Distance(newPosition, info.point) > stepDistance && !otherFoot.IsMoving() && lerp >= 1)
            {
                lerp = 0;
                Vector3 direction = Vector3.ProjectOnPlane(info.point - currentPosition,Vector3.up).normalized;

                float angle = Vector3.Angle(body.forward, body.InverseTransformDirection(direction));

                isMovingForward = angle < 50 || angle > 130;

                if(isMovingForward)
                {
                    newPosition = info.point + direction * stepLength + footOffset;
                    newNormal = info.normal;
                }
                else
                {
                    newPosition = info.point + direction * sideStepLength + footOffset;
                    newNormal = info.normal;
                }

            }
        }

        if (lerp < 1)
        {
            Vector3 tempPosition = Vector3.Lerp(oldPosition, newPosition, lerp);
            tempPosition.y += Mathf.Sin(lerp * Mathf.PI) * stepHeight;

            currentPosition = tempPosition;
            currentNormal = Vector3.Lerp(oldNormal, newNormal, lerp);
            lerp += Time.deltaTime * speed;
        }
        else
        {
            oldPosition = newPosition;
            oldNormal = newNormal;
        }
    }

    private void OnDrawGizmos()
    {

        Gizmos.color = Color.red;
        Gizmos.DrawSphere(newPosition, 0.1f);
    }

    public bool IsMoving()
    {
        return lerp < 1;
    }
}

IKTargetFollowVRRig

using UnityEngine;

[System.Serializable]
public class VRMap
{
    public Transform vrTarget;
    public Transform ikTarget;
    public Vector3 trackingPositionOffset;
    public Vector3 trackingRotationOffset;
    public void Map()
    {
        ikTarget.position = vrTarget.TransformPoint(trackingPositionOffset);
        ikTarget.rotation = vrTarget.rotation * Quaternion.Euler(trackingRotationOffset);
    }
}

public class IKTargetFollowVRRig : MonoBehaviour
{
    [Range(0,1)]
    public float turnSmoothness = 0.1f;
    public VRMap head;
    public VRMap leftHand;
    public VRMap rightHand;

    public Vector3 headBodyPositionOffset;

    void LateUpdate()
    {
        transform.position = head.ikTarget.position + headBodyPositionOffset;
        float yaw = head.vrTarget.eulerAngles.y;
        transform.rotation = Quaternion.Lerp(transform.rotation,Quaternion.Euler(transform.eulerAngles.x, yaw, transform.eulerAngles.z),turnSmoothness);

        head.Map();
        leftHand.Map();
        rightHand.Map();
    }
}

AnimateOnInput

using System.Collections.Generic;
using UnityEngine;
using UnityEngine.InputSystem;

[System.Serializable]
public class AnimationInput
{
    public string animationPropertyName;
    public InputActionProperty action;
}

public class AnimateOnInput : MonoBehaviour
{
    public List<AnimationInput> animationInputs;
    public Animator animator;

    void Update()
    {
        foreach (var item in animationInputs)
        {
            float actionValue = item.action.action.ReadValue<float>();
            animator.SetFloat(item.animationPropertyName, actionValue);
        }
    }
}
